• Model Name:

    Printer Ultra 4000 3304 -35pl

  • Product Description
  • New Ultra 4000 Series Polaris Printers

    The Best Choice of Solvent Printer

Follow Us: Facebook Twitter LinkedIn Google+ Addthis
Model Number: Printer Ultra 4000 3304     Ink Type Solvent
Plate Type: Roll to Roll
Max. Printing
Width:
3.2m / 10.5ft
Printhead 4pcs Polaris -35PL
Colors: 4 Colors (CMYK)
RIP Software: Maintop
(Photoprint / Ultra Print Optional)

Ink Supply System: Syphonage
Media Heating: Front & Rear
Ink Drying System: Infrared dryer
Compatible OS: Win XP& Win7(32bite)
Interface PCI  LVDS / USB
Input Power: Single AC + Grounded 220V±10%
Gross Power: 4800W
Warranty: One Year for Main Parts
Certificate: CE / QA / CSI, etc.
Packing Dimensions
(L*W*H):
4.90*1.13*1.13m
Application: Flex Banner, PVC, Vinyl, Paper and
other advertisement materials.







Technical Specifications

Model Name                            Ultra4000 3304
Printer Head Quantity 4pcs Sepctra Polaris 35pl
Printer Width Printing Width 3.2m
 Printing Speed 4PASS 62m2 /h
3PASS 85m2 /h
2PASS 120m2 /h
Image Format TIFF,JPG,EPS,PDF
RIP Software Maintop/Photoprint Optional
Interface USB2.0(Window2000/nt/xp etc.)
Power  AC 220V, 50HZ±10%, UPS is required
Operation System Windows XP/Win 7 Workstation
PC Configuration System: Windows XP SP2 (English Version)/
Windows 7 (Professional Version
CPU: Intel Dual Core I5
RAM: 2GB
HardDisk: SATA 640G
Hard Disk Format:NTFS
VGA Card:SDC ATI 1G
CD Rom: DVD Recordable
Space for Disk C:100G at least
Temperature/Humidity Temperature 20-30℃, Humidity 60-70%
Packing Size L/W/H: 4.90x1.13x1.13m
G.W./N.W. 800kg/460kg

Remarks: The data is subject to change without prior notice. The speed will be varied due to different PC settings.
