• Model Name:

    Printer Ultra Star 5304/6

  • Product Description
  • 5m Solvent Printer

    Printheads: StarFire 1024

    Maximum Speed: 420 ㎡/h

    Printing Width: 5.2m

    Ink Type: Solvent

Follow Us: Facebook Twitter LinkedIn Google+ Addthis



5m Solvent Printer Ultra Star 5304

5m Solvent Printer Ultra Star 5304



SarFire Solvent Printers
Printer Model Ultra Star Series
Print Head
StarFire 1024 10PL/25PL
Printing Width 5.2m
Printing Speed Printing Mode Ultra Star 5304/6
2PASS 450㎡/h
3PASS 300㎡/h
4PASS 240㎡/h
Ink Type CMYK Solvent Ink
Media Media Processing Roll to Roll + Auto Feeding + Auto Roll Up
Media Heating Pre&Post-Media Heating
Media Type Outdoor Solvent based roll media(Flex,Vinyl,Backlit Banner etc)
Image Format TIFF, JPG, EPS, PDF
RIP Software Maintop(Standard) / Photoprint/Onyx/Caldera/Print Factory (Optional)
Interface
High Speed PCIE LVDS
Operating System Win10 Workstation
Power Supply AC220V 50HZ±10%,UPS is required
Power 7000W
PC Configuration

System:  Windows 10 (Professional Version)

CPU: Intel Dual Core i5/i7

RAM: KST  8/16GB

Hard Disk: 2TB

SSD :250G for Disk C only

Motherboard:ASUS

Temperature/Humidity Temperature 20-30, Humidity 60-70%
Packing Size  LxWxH: 8.50x2.23x2.20m
G.W./N.W. 3600/3100kg
Remark: The data is subject to change without prior notice. The speed will be varied due to different PC settings.
